Stepper Motor Driver for NEMA 17 Binghe SMC02 Stepper Motor Driver Controller Stepper Motor with Display Forward/Reverse Stepper Motor Driver Control PLC Serial Communication for NEMA 17 23 Moto
Stepper Motor Driver for NEMA 17 Binghe SMC02 Stepper Motor Driver Controller Stepper Motor with Display Forward/Reverse Stepper Motor Driver Control PLC Serial Communication for NEMA 17 23 Moto
Product overview The integrated controller and driver Binghe SMC02 is a special single-axis stepper motor control module. With a wide voltage compatibility range, it supports speed, angle and delay settings for precise control of industrial equipment. The integrated TTL serial communication function allows remote control and seamless integration with automation systems. Instructions for use: Forward/reverse control: support 1-9999999 pulses for forward/reverse operation, adjustable as needed. Delay and Cycle Adjustment The delay ranges from 0.1 to 999 seconds; cycles can be adjusted up to 1-9999 times. Parameter Preservation: The power-off memory function ensures that the settings are preserved. Connection Instruction Suitable for different types of stepper motors and compatible drivers. Factory Self Lock Function: For different requirements, self-locking can be achieved by modifying the EN signal port on the back of the module. Parameters: Applicable motor: stepper motor Control axle: single axle. Motor signal: common negative Power supply range: DC 10-30V universal Drive capacity: 4A. Command features: streamline and optimize multiple commonly used instructions Acceleration and deceleration control: Yes Input reverse polarity protection: yes. Remote control of communication: Serial TTL port Main system functions: automatic, manual, setup, serial interface control Speed range: 0.1~999 rpm. Number of forward pulses: 1-9999999 pulses. Reverse pulse number: 1-9999999 pulses. Cycle working hours: 1-9999 times. Forward rotation delay time: 0.1-999 seconds Reverse delay time: 0.1-999 seconds Range of subdivision selection: 1-32 subdivision Environment: -5°C - 60°C (non-condensing). Products include: 1 x stepper motor driver for NEMA 17.
Product Features
- Controller and driver: Built-in stepper motor driver control and driver functions for precise motor control and real-time monitoring of operating status.
- Forward and backward: SMC02 stepper motor driver. Easy to change the direction of rotation at the touch of a button or potentiometer for nema 17 23.
- 3 control modes: stepper motor driver flexible control via external buttons or other driving commands for individual adjustment.
- 9 built-in standard workflow programs: cover most applications stepper motor for different scenarios and easy adjustment of parameters.
- HD LCD display: clear display of speed, delay and cycle time stepper motor for precise control and easy parameter adjustment.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Stepper Motor Driver for NEMA 17 Binghe SMC02 Stepper Motor Driver Controller Stepper Motor with Display Forward/Reverse Stepper Motor Driver Control PLC Serial Communication for NEMA 17 23 Moto
Stepper Motor Driver for NEMA 17 Binghe SMC02 Stepper Motor Driver Controller Stepper Motor with Display Forward/Reverse Stepper Motor Driver Control PLC Serial Communication for NEMA 17 23 Moto
Stepper Motor Driver for NEMA 17 Binghe SMC02 Stepper Motor Driver Controller Stepper Motor with Display Forward/Reverse Stepper Motor Driver Control PLC Serial Communication for NEMA 17 23 Moto
Product overview The integrated controller and driver Binghe SMC02 is a special single-axis stepper motor control module. With a wide voltage compatibility range, it supports speed, angle and delay settings for precise control of industrial equipment. The integrated TTL serial communication function allows remote control and seamless integration with automation systems. Instructions for use: Forward/reverse control: support 1-9999999 pulses for forward/reverse operation, adjustable as needed. Delay and Cycle Adjustment The delay ranges from 0.1 to 999 seconds; cycles can be adjusted up to 1-9999 times. Parameter Preservation: The power-off memory function ensures that the settings are preserved. Connection Instruction Suitable for different types of stepper motors and compatible drivers. Factory Self Lock Function: For different requirements, self-locking can be achieved by modifying the EN signal port on the back of the module. Parameters: Applicable motor: stepper motor Control axle: single axle. Motor signal: common negative Power supply range: DC 10-30V universal Drive capacity: 4A. Command features: streamline and optimize multiple commonly used instructions Acceleration and deceleration control: Yes Input reverse polarity protection: yes. Remote control of communication: Serial TTL port Main system functions: automatic, manual, setup, serial interface control Speed range: 0.1~999 rpm. Number of forward pulses: 1-9999999 pulses. Reverse pulse number: 1-9999999 pulses. Cycle working hours: 1-9999 times. Forward rotation delay time: 0.1-999 seconds Reverse delay time: 0.1-999 seconds Range of subdivision selection: 1-32 subdivision Environment: -5°C - 60°C (non-condensing). Products include: 1 x stepper motor driver for NEMA 17.
Product Features
- Controller and driver: Built-in stepper motor driver control and driver functions for precise motor control and real-time monitoring of operating status.
- Forward and backward: SMC02 stepper motor driver. Easy to change the direction of rotation at the touch of a button or potentiometer for nema 17 23.
- 3 control modes: stepper motor driver flexible control via external buttons or other driving commands for individual adjustment.
- 9 built-in standard workflow programs: cover most applications stepper motor for different scenarios and easy adjustment of parameters.
- HD LCD display: clear display of speed, delay and cycle time stepper motor for precise control and easy parameter adjustment.
Original: $214.00
-65%$214.00
$74.90Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Stepper Motor Driver for NEMA 17 Binghe SMC02 Stepper Motor Driver Controller Stepper Motor with Display Forward/Reverse Stepper Motor Driver Control PLC Serial Communication for NEMA 17 23 Moto
Product overview The integrated controller and driver Binghe SMC02 is a special single-axis stepper motor control module. With a wide voltage compatibility range, it supports speed, angle and delay settings for precise control of industrial equipment. The integrated TTL serial communication function allows remote control and seamless integration with automation systems. Instructions for use: Forward/reverse control: support 1-9999999 pulses for forward/reverse operation, adjustable as needed. Delay and Cycle Adjustment The delay ranges from 0.1 to 999 seconds; cycles can be adjusted up to 1-9999 times. Parameter Preservation: The power-off memory function ensures that the settings are preserved. Connection Instruction Suitable for different types of stepper motors and compatible drivers. Factory Self Lock Function: For different requirements, self-locking can be achieved by modifying the EN signal port on the back of the module. Parameters: Applicable motor: stepper motor Control axle: single axle. Motor signal: common negative Power supply range: DC 10-30V universal Drive capacity: 4A. Command features: streamline and optimize multiple commonly used instructions Acceleration and deceleration control: Yes Input reverse polarity protection: yes. Remote control of communication: Serial TTL port Main system functions: automatic, manual, setup, serial interface control Speed range: 0.1~999 rpm. Number of forward pulses: 1-9999999 pulses. Reverse pulse number: 1-9999999 pulses. Cycle working hours: 1-9999 times. Forward rotation delay time: 0.1-999 seconds Reverse delay time: 0.1-999 seconds Range of subdivision selection: 1-32 subdivision Environment: -5°C - 60°C (non-condensing). Products include: 1 x stepper motor driver for NEMA 17.
Product Features
- Controller and driver: Built-in stepper motor driver control and driver functions for precise motor control and real-time monitoring of operating status.
- Forward and backward: SMC02 stepper motor driver. Easy to change the direction of rotation at the touch of a button or potentiometer for nema 17 23.
- 3 control modes: stepper motor driver flexible control via external buttons or other driving commands for individual adjustment.
- 9 built-in standard workflow programs: cover most applications stepper motor for different scenarios and easy adjustment of parameters.
- HD LCD display: clear display of speed, delay and cycle time stepper motor for precise control and easy parameter adjustment.
